Features

• Universal fit for a wide range of turbo applications, slip fit inlets and outlets
• The new intercooler maximizes space in the already narrow bumper area, increasing size and volume; reduces temperatures up to 40°F and adds nearly 20 horsepower on modified cars compared to the stock core
• Constructed from cast aluminum with a bar and plate design, increasing both cross-sectional and frontal surface area by 50%+, dramatically improving performance on and off the track
• High-flow cast end tanks are TIG welded; all joints TIG welded to prevent cracking and wear; excellent quality and durability
• Made of high-quality durable T-6061 aluminum, can withstand up to 500°F; each end tank features precision CNC machined hose fittings compatible with factory intercooler hoses
• The accessories in the photos are included
• 1 year warranty for any manufacturing defect

Technical Specifications

• Cooling Type: Air to Air
• Core Construction: Bar and Plate
• Overall Size: 27 x 6 x 2.5 in.
• Core Size: 22 x 6 x 2.5 in.
• Inlet Size: 2.25 in.
• Outlet Size: 2.25 in.
• Flow Rate: 330 CFM @ 28 inH2O (1 psi), 540 CFM @ 50 inH2O (2 psi)
• HP Rating: 800 HP
• Material: T-6061 aluminum
• Finish: Polished
